Distance sensor Infrared Sharp GP2Y0A41SK0F 4-30cm
Product information:
The Sharp GP2Y0A41SK0F distance sensor/rangefinder measures distance in the range of 4-30cm with a reflected beam of infrared light. By using triangulation, the sensor can provide consistent values that are less affected by surface reflection. The Sharp GP2Y0A41SK0F provides an analog voltage that corresponds to the distance to the reflecting object.
The analog output voltage can easily be read out for an ADC or analog input of a microcontroller (such as an Arduino or Raspberry Pi).
With two mounting eyes to easily attach the sensor to your project.
Specifications:
Measuring range: 4-30cm
Analog output
Dimensions: 29.5x13x13.5mm
Consumption: 12mA
Supply voltage: 4.5-5.5V DC
Check out the website link for an Arduino library.
Click to view the product's website.
>
