Digital multimeter UNI-T UT133A

Product information:

UNI-T digital multimeter (type UT133A) for measuring DC and AC voltage, DC and AC current, resistance, capacitance and continuity.
Additionally, you can measure temperature (with the included K-type thermocouple) and test diodes.

- Over-voltage/over-current audible alarm
- High voltage warning
- Auto power off (can be turned off)
- Low consumption
- With buzzer for continuity (circuit) measurements
- Also tests diodes and measures temperature
- With space for the measuring pins
- Works on 2 AA penlite batteries
- With LCD lighting

Click to view the product's website.Click to view the product's website.

Specifications

:
Brand:UNI-T
Meter type:Digitale multimeter
Features:AC spanning, AC-stroom, capaciteit, continuïteit, DC spanning, DC-stroom, weerstand
Display:LCD (5999)
Range of voltage measurement:600mV/6V/60V/600V
Precision of the DC voltage measurement:+/-(0,5% + 3 digit)
Range of AC-voltage measurement:600mV/6V/60V/600V
Precision of the DC voltage measurement:+/-(0,7% + 3 digit)
Range DC current:600µA/6mA/60mA/600mA/6A/10A
Precision of the DC current measurement:+/-(1% + 3 digit)
Range AC current:600µA/6mA/60mA/600mA/6A/10A
Precision of the AC current measurement:+/-(1% + 3 digit)
Range resistance:600Ω/6kΩ/60kΩ/600kΩ/60MΩ
Range of the capacity measurement:9,999nF/99,99nF/999,9nF/9,999µF/99,99µF/999,9µF/9,999mF
Precision of the resistance meaurement:+/-(4%+ 5 digit)
Testing options:Diodes, Temperatuur, Batterijen
Conformity with norm:CAT III 600V EN 61010
Dimensions (W X H x D):76,5x155x49mm
Background light:ja
Range temperature measurement:-40...1000

Documentation

:
icon_filetype_pdf
Datasheet Specs_UT133.pdf (English)
icon_filetype_pdf
User manual (English):
Manual_UT133.pdf
